Any Hook Shot Blasting Machines are available, please feel free to contact us!
| weight (kg) | 1500 |
| use | Shot Blasting /Sand Blasting |
| cleaning process | steel shot cleaning |
| warranty | 12 months |
| place of origin | Shandong,China |
| brand name | Jiabeide |
| video outgoing-inspection | Provided |
| machinery test report | Provided |
| core components | PLC, Engine, Gearbox, motor, Gear, Pump |
| material | Metal / Coil |
| dimension(l*w*h) | Design |
| key selling points | Professional |
| PLC system | Siemens, Omron or famous brand in china |
| Cleaning Process | Shot blasting/Wheel blasting By motor driving |
| Dust collector | Cartridge/Bag type filter pulse reverse |
| Blast chamber | 10mm shell &10mm Mn Alloy liner |
| Blast cleaning speed | 0.5-4m/min |
| surface finish speed | SA2.5-SA3.0 |
| Advantages | 1.Various for plate,beam,pipe,sheet 2.Fully Automatic |
| Operate | Fully Automatic Continuous blasting cleaning |
Castings
Forgings
Gas cylinders
Cast pipes and elbows
Large fabricated metal components
Cleaning Process: Shot blasting / wheel blasting, driven by motor
Surface Finish: SA2.5–SA3.0
Surface Roughness: 25–130 μm
Blasting Speed: 0.5–4 m/min
Operation: Fully automatic, continuous blasting
Voltage: 110V/220V/240V/380V
Blast Chamber: 10mm steel plate + 10mm manganese alloy liner
Dust Collector: Cartridge / bag type, pulse reverse cleaning
PLC System: Siemens, Omron or top Chinese brands
Weight: Approx. 1,500 kg
Origin: Qingdao, China
Brand: JBD
Warranty: 12 months
Certification: CE
Roller Conveyor System
Structure: Infeed, intermediate and outfeed rollers
Load capacity: 2 tons per meter
Roller spacing: 1,000 mm
Speed: 0.5–4 m/min, adjustable
Drive: Variable-speed reducer
Protection: Alloy sleeves inside chamber, service life ≥ 4,000 hours
Blast wheels: Mounted on side walls, angle-adjustable for full coverage
Liner: Manganese alloy for heavy abrasion resistance
Doors: Manual or pneumatic
Screw conveyor: Collects spent shot at chamber bottom
Bucket elevator: Transports shot to separator
Separator: Screen + air classification, recycles qualified steel shot
Efficiency: 99.9%
Configuration: Cyclone pre-collector + cartridge / bag filter
Features: Pulse cleaning, low emission, environmentally friendly
Operation: Automatic / manual
Controller: PLC (Siemens / Omron / Chinese brands)
Safety: Emergency stop on panel and line, power indicator
1.Wide Application:Suitable for various workpieces: plates, beams, pipes, profiles and structural parts.
2.Fully Automatic:Continuous operation, high productivity, low labor cost.
3.Stable & Reliable:Mature technology, low failure rate, easy maintenance.
4.Custo Design:Tailored to workpiece size, weight and output requirements.
5.Durabe Construction:Heavy-duty chamber and wear-resistant liners.
6.Clean & Safe:High-efficiency dust collector, CE certified.
7.Competitive Price:Factory direct supply.
8.Short Lead Time:25–45 days for 1 set; >1 set: To be negotiated.
Custom Solutions
We design and manufacture non-standard shot blasting machines according to your requirements:
·Workpiece dimensions and weight
·Production capacity
·Surface quality standard
·Workshop layout
From design to commissioning, we provide one-stop solutions for your surface treatment needs.
